Series 5 aluminium alloy with magnesium as the main alloy element. It has good corrosion resistance, good welding performance, and good fatigue strength. It could only cold processing to improve strength but cannot be strengthened by heat treatment. Among them, 5052 aluminium sheets have good formability and corrosion resistance. And it is a kind of anti-rust aluminum. If you are interested in learning about this product, please contact us.
Basic information
Alloy | 1050/1100/3003/3105/5052/5754 |
Temper | O, H12, H14, H16, H18, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, H 116 |
Thickness(millimeter) | 0.15-600 |
Width(millimeter) | 20-2600 |
Length(millimeter) | 500-16000 |
Typical products | Aluminium sheet for oxide, sheet metal for marine, fuel tank device |
The above is 5052 aluminium sheet manufacturers to introduce 5052 aluminum plate-related information. More information about the 5052 aluminum sheet specification table, 5052 aluminum sheet manufacturers, and other information details consultation telephone.
Use of 5052 aluminium sheet products
The main alloying element of the 5052 alloy aluminum sheet is magnesium. And a small amount of metal alloy adds to it. It has the performance of forming processing, corrosion resistance, and re-weldability of aluminum sheets.
Series 5 is a material for the production of ship decks, subway floors, car doors, and curtain wall panels. It is mostly to make mailbox material, tank material, door sheet material, high voltage switch shells, etc.
It has a use in the manufacture of fuel tanks, oil pipes, sheet metal parts for rail transit, and vehicles. It has a wide range of uses in ships and yachts, stamping parts, various lamp brackets, and industrial rivets. Also, the usage is hardware products, electronic accessories, mobile phone shells, household appliance shells, etc.
- 5052 aluminum alloy sheet use: aluminum alloy for automobiles, 3C products, computer brackets, curtain wall panels, oxide materials. can tanks/covers, shutters, trolley boxes, aluminum furniture, door panels/door handles, signs, decoration, etc.
- 5052 aluminum alloy thick plate use: silo, flange material, GIS shell, underwear mold/shoe mold, gas reservoir, precision machining, etc.
- 5052-H32 aluminum plate is useful in the field of automotive aluminum. Such as automobile engine outer plate, bus trunk plate, bus anti-skid decorative plate, automobile fuel tank aluminum plate, etc.
The performance of 5052 aluminium sheet
The density: is 2.68kg/cubic meter.
Tensile strength (σb): 170~305MPa.
Conditional yield strength: σ0.2 (MPa): ≥65.
Modulus of elasticity (E): 69.3~70.7Gpa.
It has an annealing temperature of -345°C.
- Homogenization annealing: heating 440 °C, Keep warm for 12~14h, Air-cooled.
- Rapid annealing: heating 350~410°C, Heat preservation time: 30~120min, Air or water cooled.
- High temperature annealing: when heating 350~420 °C, the thickness of the finished product ≥6mm or <6mm. The holding time is 2~10min or 10~30min, and the air cooling.
- Low temperature annealing: heating 250~300 °C or 150~180 °C, holding time 1~2h, air cooling.
The price of 5052 aluminium sheet
Analysis of 5052 aluminum plate manufacturers’ 5052 aluminum plate price affects the price of the most important factors. The specific specifications and the price of aluminum ingots in the market are all important factors affecting the price.
5052 aluminum sheet price = market aluminum ingot price + 5052 aluminum sheet processing fee.
Advantages
- 5052 aluminum sheet has high strength, high fatigue strength, high plasticity, and corrosion resistance. And it has good plasticity when hardened by semi-cooling.
- There is no peeling, bubbles, rough surface or local mechanical damage on the surface of the aluminum sheet. And there are no cracks, corrosion spots, and nitrate traces on the surface of the aluminum sheet.
- Our company has 6 semi-continuous casting production lines and 10 continuous casting and rolling production lines. Our company also has 44 sets of other large-scale processing equipment. Our company has an annual production capacity of 700,000 tons.
If you have a favorite product, please contact us quickly. Our contact number is 15890666512, and the email address is admin@worthwillal.com.
