PE coated aluminium sheet is a new kind of material, the surface is coated with a layer of PE paint, so that the aluminum plate has UV protection, acid and alkali resistance, high weather resistance and other excellent properties, the life of outdoor used can be as long as 20 years.
Advantage
- UV resistant coating
- Decorative design
- Good gloss and smoothness
- Corrosion resistance
- Anti-freezing
- Rust resistant
- Flame retardant
- Small chromatic aberration
- Year of guarantee more than 10 years,etc.
Applications
- Polyester PE coated aluminum coils are used to produce aluminum ceilings,aluminum plastic panels, aluminum honeycomb panels, aluminum insulation panels,aluminum roller shutter foam insulation slats,gutters and downspouts,etc.
- Polyester PE coated aluminum coils are also suitable for interior decoration and advertising boards.
Specification of PE coated aluminium
Common alloy:
1 Series:1050/1060/1070
2 Series:3003/3004/3015
5 Series:5005/5052/5050
6 Series:6061,etc.
Temper: O/ H14/H24/H26 etc.
Thickness:0.02-5.0MM
Width:10-1850MM
The length and width can be customized according to customer requirements.
Coating
Color aluminum coating is the coating coloring treatment of the surface of aluminum plate or coil. Its common fluorocarbon color coated aluminum, polyester color coated aluminum, widely used in aluminum-plastic board, aluminum veneer, aluminum honeycomb panel, aluminum ceiling and so on. Its performance is very stable, not easy to be corroded, and the surface can reach 30 years of quality assurance after special treatment. Color-coated aluminum is the most popular new aluminum material at present.
The Coating Processing Line
- Put Put the plain coils in the decoiling machine and let it trough the Material storage tower.
- Pres-processing. Firstly through the alkaline water tank to degrease the coil,secondly use the tap water to clean,then the acid to neutralize the remnant alkali,at last completely clean with pure water.
- (the temperature is 210-230 degree Celsius.)
- Add the chromium to passivate the coil and enhance the adhesive strength.
- Coat the bottom of the coils with clear varnish or white and gray paint.
- Drying
- Use air cooling system or water cooling system to cool them down.
- Drying again.(water cooling system)
- According to customers’ requirement to make second coating.
- Drying.
- Covering the surface of coils with plastic film.
- Packaging with inner paper tube about 15-20mm in thickness.
- Sending them to the storage.
Classification of color coated aluminium product
- Solid:White, gray and black are Solid colors. Generally used in ceiling,gutter, Tank body material and license plate material.
- Metallic: Metallic silver, flash silver, white silver gray and other metallic colors. Generally used in facades and others.
- Coated Mirror:The common color is silver, gold,light gold,black.The commonly used film color is blue and yellow, which are medium and low viscosity. Often used in aluminum strip, interior trim and ceiling material. Common alloy 1060 H18 H14/H24 3003.
- Brushed Coated:The common color is silver, gold, light gold. Common alloy 1060 H18 H14/H24 3003. Often used in aluminum edge strips, mobile phone cases, computer hosts, cabinet panels and ACP boards.
- Imitation Wooden/Imitation Stone: Customized according to the sample provided by the customer.
- Film Coated: Customized according to the sample provided by the customer.
Quality control
We have the complete system of Quality Control. You can safe to buy and use, if any questions, contact us and we will solve it in time and make you satisfy.
Our company
Henan Worthwill Industry Co., Ltd is the international sales company of Henan Jurun New Material Co., Ltd. Our company is a private Joint-stock Company, registered Capital by 50,000,000 CNY, covers an area of 80,000 square meters with more than 200 employees, including more than 30 technical and management personnel. We are led by technological innovation, integrated on Scientific Research, Marketing and Production, supported by Henan Provincial Commerce Department as an Export-Oriented enterprise.
If you are interested in our products, please contact me!
